The Winco RP50 Mobile Diesel Generator offers a FPT diesel engine, up to 47.5 kW of power, a 3-position voltage selector switch, standard receptacle panel, and a premium DOT approved trailer.

FEATURES

• Switchable Voltage: Three-position voltage selector switch offers single phase 120/240V, three phase 120/208V, and three phase 277/480V.
• Brushless Industrial Gen End: Offers +/-1% automatic voltage regulator.
• FPT Diesel Engine: Tier 4 Final, 4-cylinder, electronic governor, and low oil protection.
• Fuel Tank: 95 gallon tank for 27 hour runtime at full load, 110% containment.
• DSE7310 MKII Controller: Engine display and protection, Genset disply and protection, Audible alarm, Engine exerciser.
• Camlock Receptacles: Quickly connects load without hard-wiring.
• Single Phase Receptacles: Two 20A 120V NEMA 5-20 GFCI and two 50A 120/240V CS6369 receptacles.
• External E-Stop: Located outside the unit in case of an emergency.
• Fold-Down Panel: Easily access the electrical panel for maintenance.
• Solar Battery Charger: Keeps your start battery charged without needing an extension cord.
• Oil-Field Skid: Ready to work with its rugged design, fuel tank, and containment
• Single-Point Lifting Eye: One lifting eye for quick and easy moving.
• Fork Pockets: Convenient fork pockets integrated into the unit.
• Single Axle DOT Trailer: Includes electric brakes and 2″ ball hitch.

DOWNLOADS

RP50 Spec Sheet

DSE7310 MKII Controller

OPTIONS

• 5A Battery Charger Upgrade.
• 650 CCA Battery.
• Single Dedicated Voltage.
• DSE8610 Parallelling Controller Upgrade.
• Spare Tire and Optional Mounting Bracket.
• Tool Box Assembly.
• Optional Hitch: 2-5/16″ Ball or 3″ Pintle.
