The MQ Power Whisperwatt DCA70SSJU4F mobile diesel generator offers up to 62 kW of power at a quiet 66 dBA.

FEATURES

• Voltage selector switch offers the operator a wide range of voltages that are manually selectable. Fine tuning of the output voltage can be accomplished by adjusting the voltage regulator control knob to obtain the desired voltage.
• ECU845 microprocessor-based digital generator controller with remote 2-wire start/stop control, operational temperature range of -40° to 85° C, high visibility LCD display with heated screen and alphanumeric readout, modbus interface for gauge panel and expansion options, and AC monitoring along with fuel and DEF level indicators.
• Analog generator instrumentation including AC ammeter, AC voltmeter, frequency meter, ammeter phase selector switch, voltmeter phase selector switch, and voltage regulator adjustment potentiometer.
• Digital engine gauges including oil pressure, water temperature, battery volts, engine speed, engine load, DEF fluid level, and fuel level.
• Automatic safety shutdown system monitors water temperature, engine oil pressure, overspeed, and overcrank; warning lights indicate abnormal conditions.
• Main line circuit breaker with 168A rating.
• Fully covered power panel with three-phase terminals and single phase receptacles for fast and convenient hookup for most applications including temporary power boxes, tools and lighting equipment.
• Brushless alternator reduces service and maintenance requirements and meets temperature rise standards for Class H insulation systems.
• Open delta alternator design provides virtually unlimited excitation for maximum motor starting capability.
• Automatic voltage regulator (AVR) provides precise regulation.
• Electronic Governor Control maintains frequency to within ±0.25% from no load to full load.
• Full load acceptance of standby nameplate rating in one step (NFPA 110, para 5.6.3.1.2).
• Simultaneous single and three phase power.
• Dual frequency capability allows for operation at 50 Hz or 60 Hz.
• Heavy duty, 4-cycle, direct injection, turbocharged, charge air cooled Tier 4 Final John Deere diesel engine.
• Block Heater and Crankcase Vent (CCV) Heater standard.
• Fuel/water separator removes condensation from fuel for extended engine life; panel mounted alarm light included.
• Internal fuel tank with direct reading fuel gauges.
• Sound attenuated, weather resistant, steel housing.
• E-coat and powder coat paint provides durability and weather protection.
• Fully lockable enclosure allows safe unattended operation.
• Emergency Stop Switch standard.

DOWNLOADS

DCA70SSJU4F Spec Sheet

DCA70SSJU4F Manual

Whisperwatt Three Phase Comparison Chart

Whisperwatt Generators Brochure

MQ Power Generator Quick Reference Chart

TRAILER OPTIONS

• TRLR70USH/E
• TRLR75XF2 (with 100 gallon fuel cell)

(See below for further information)

OPTIONS (Order with Generator)

• Audible Alarm (MQPAUDIBLEALARM) – ADD $276.00

• Auto Air Shutoff Valve with Auto Reset (MQPASVA220T4F) – ADD $2,864.00
• Battery Charger (MQPBCKIT-J) – ADD $456.00

• Battery Disconnect Switch (MQPBATTSWITCH125) – ADD $193.00

• Camlock Connections (Single Set of Five) (CAMLOK1KIT45E) – ADD $635.00

• DEF Replenishment System (see below)

• External Fuel Three-Way Manual Fuel Valve (MQP3WAYVALVE70J) – ADD $711.00

• External Fuel Three-Way Automatic Fuel Valve (MQP3WAYAUTOKIT-C) – ADD $808.00
• Fire Extinguisher with Bracket (MQPFE05KIT) – ADD $353.00
• Low Coolant Shutdown (LCSD12KIT) – ADD $794.00

• Power Balance Kit (MQPPBNK70J4F3) – ADD $5,433.00

• Solar Battery Charger (MQPSOLAR12) – ADD $947.00
