Info

Our most popular swing gate operator delivers unsurpassed performance and secure access to your property.

Access your property like never before. With MyQ^®Technology you can monitor and control your gate from anywhere and get in quickly and securely with the built-in interference eliminating Security+ 2.0® radio. Our industry-leading power management technology extends battery backup for up to 24* days without recharging, providing greater reliability and security. No other company can offer you that peace of mind.

Connectivity

• MyQ Technologyenables you to securely monitor and control your gate operator and houselights with your smartphone for greater peace of mind.
• Alertscan be received as email or pop-up (push) notifications on your mobile device so that you always know the status of your gate operator.
• MyQ Mobile Appis a free download with no annual activation fee.
• Requires828LM MyQ Internet Gateway to connect to MyQ Smartphone App.

Performance

• Battery Backupsafeguards your property by providing up to 500 cycles* or up to 24 days* of standby power when the power is down.
• Solar Ready Ultra Reliable Systemdelivers power when you need it most to operate the gate and is extremely power efficient at all other times to maximize solar performance. Home owners may qualify for 30% solar tax credit.
• Gate Sizerated for gates up to 18 ft. in length or weighing up to 1600 lbs.
• Commercial Duty Cast Aluminum Housing with Heavy-Duty DC Motorpowerful enough to perform in the most demanding applications. Soft start/stop operation extends operator and hardware life for heavy-duty gate use.

Safety and Security

• Security+ 2.0® Patented Multi-Frequency Secure Radio Technologyvirtually eliminates interference and offers 2X the range of standard remotes so you can access your home quickly and safely.
• Quick Close/Anti Tailgate Selectable Featurequickly secures gate and prevents unauthorized access.
• Plug-in Loop Detector Inputs Innovative Designensures vehicles are easily identified to exit property or interrupt gate travel if a vehicle is in its path.
• Safety Inputsprovided for the addition of safety reversing devices. Each entrapment point should be protected with its own device.
• UL/cUL Listedtested to the most stringent industry guidelines.

Battery Back Up Battery: 2-7 AH. Cycles: 500. Standby Time: 24 days

Capacity: 1600lbs x 8 ft, 1200 lbs x 12 ft, 800 lbs x 16 ft and 600 lbs x 18 ft”

Dimensions: The dimensions of the arm of the operator are 6″ x 40″”One of the boxes of the operator is 16″ x 13″

Resources

LA500DC Product Guide

LA500DC Installation Manual
