One of our most popular swing gate operators just got even better in delivering unsurpassed performance and secure access to your property.

Access your property like never before. With MyQ® Technology you can monitor and control your gate from anywhere and get in quickly and securely with the built-in interference eliminating Security+ 2.0® radio. Best in class power management technology extends battery backup for up to 97 days* without recharging, providing greater security and reliability. No one else can offer you that peace of mind.

Connectivity
MyQ Technology enables you to securely monitor and control your gate operator and houselights with your smartphone for greater peace of mind.

Alertscan be received as email or pop-up (push) notifications on your mobile device so that you always know the status of your gate operator.

MyQ Mobile Appis a free download with no annual activation fee.

Performance
Battery Backupsafeguards your property by providing up to 400 cycles* or up to 97 days* of standby power when the power is down.

Solar Ready Ultra Reliable Systemdelivers power when you need it most to operate the gate and is extremely power efficient at all other times to maximize solar performance. Home owners may qualify for 30% solar tax credit.

Heavy-Duty Cast Aluminum Housing DC Motorpowerful enough to perform in the most demanding applications. Soft start/stop operation extends operator and hardware life for heavy-duty gate use.

Gate Sizerated for gates up to 16 ft. in length or weighing up to 850 lbs.

Safety and Security
Security+ 2.0® Patented Multi-Frequency Secure Radio Technology virtually eliminates interference and offers 2X the range of standard remotes so you can access your home quickly and safely.

Safety Inputsprovided for the addition of safety reversing devices. Each entrapment point should be protected with its own device.

UL/cULListed tested to the most stringent industry guidelines.

Specs

Battery Back Up
Battery: 2-7 AH. Cycles: 400. Standby Time: 97 days. Battery backup operation 400 cycles (10ft/850 lb. swing gate)

Capacity
850 lbs x 10 ft, 750 lbs x 12 ft, 650 lbs x 14 ft, 550 lbs x 16 ft

Dimensions
The arm of the operator is 5.5″ x 37.5″
One of the boxes of the operator is 16″ x 13″
The box part of the operator is 20″ x 16″
