The CK Power CKG1025PVM Containerized Diesel Generator offers two smaller 410kW generators paralleled together in one 48ft ISO container to provide up to 820kW of power.

GENERATOR FEATURES

• Provides up to 820kW of standby power and 750kW of prime power at 277/480VAC 3PH 60Hz.
• Two Volvo Tier 4 Final EPA/CARB Certified diesel engines.
• Two double-wall 600 gallon fuel tanks with spill containment provide approximately 22 hours of runtime at prime.
• Automatic day-tank systems allow connection to secondary fuel tanks for extended runtime.
• External fuel, oil, coolant and diesel exhaust fluid (DEF) supply and return to make re-supplying the unit easier.
• Electrically-operated common bus circuit breaker, as well as electrically-operated individual genset breakers.
• Automatic synchronization of gensets prior to accepting full load.
• Two parallel generators increase the longevity of the overall unit by preventing the effects of light loading, as one generator can shut off when the set is run at too low a load.
• External single point customer connections and controls.
• Advanced paralleling switchgear includes the gen set control and interface, paralleling controls, system monitoring, and applicable protections for both the engines and generators.
• External emergency stop button for enhanced safety.
• LED interior lighting for ease of access and maintenance.

ISO CONTAINER FEATURES

• 48ft ISO Container.
• Air intake and exhaust louvers.
• Sound-attenuated.
• Personnel doors and service access.
• Roof access ladder integrated into the ISO container.
• Five-step ladder stairs for access to operator room.
• DOT-certified chassis.

DOWNLOAD

Containerized Sample Spec Sheet

Containerized Flyer

OPTIONS

• Battery Chargers.
• Block Heaters.
• RACOR Fuel/Water Separators.
• Fire Extinguisher.
• Without Running Gear.
• Auxiliary Convenience Receptacles.
• Battery Disconnect.
• Camlock Connections.
• Other Voltage Options.
• Sand Traps and Filters (for dusty environments).
• Other Options My Be Available upon Request.
